SACC-M16FS-14CON-M - Connector
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Notes | General: NOTE: Observe the permissible bending radii when laying conductors, since the degree of protection may be put in jeopardy if the bending forces are too high. Alleviate mechanical loads upstream of the connector, e.g.by using cable ties. |
Mounting | Connection method: Solder connection |
Product properties | Product type: Circular connectors (device side) Number of positions: 14 Shielded: no Coding: no |
Dimensions | Width: 18.5 mm Height: 18.5 mm Length: 62 mm External dimensions Outside diameter: 0.25 mm |
Material specifications | Material: Die-cast zinc Flammability rating according to UL 94: V0 Contact material: CuSn Contact surface material: Au Contact carrier material: PBT |
Electrical properties | Nominal voltage UN: 60 VDC (Overvoltage category I / degree of pollution 1) 32 VAC (Overvoltage category II / degree of pollution 2) |
Connection data | Connection technology Outside diameter: 0.25 mm Conductor connection Connection method: Solder connection Contact connection type: Socket |
Connector | Connection 1 Head design: Socket Head cable outlet: straight Head thread type: M16 |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -30°C ... 95°C |
ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
ETIM | ETIM 9.0: EC002635 |
UNSPSC | UNSPSC 21.0: 39121400 |
