RC-16S1N12ZL00 - Cable connector

M23, Cable connector, series: RC, angled, shielded: no, Screw locking mechanism, No. of pos.: 16, Direction of rotation: Standard, contact connection type: Socket, Solder cup, coding: N, Alternative product in accordance with RoHS II without Exemption 6c (Pb < 0.1 %) item no.: 1241285

Product Code: 1601047 Copia - Copy

Partner cod.: 1601047 Copia - Copy

PHOENIX CONTACT

Product properties	Product type: Circular connector (cable-side) Type of the screw connection: IP68 screw Thread type: M23
Material specifications	Flammability rating according to UL 94: V0
Connection data	Conductor connection Connection method: Solder connection
Mechanical properties	Mechanical data Type of the screw connection: IP68 screw
Connector	Insulating body Coding: N Insertion/withdrawal cycles: 50 Connection method: Solder cup Contact switching type: Socket Application: Signal Number of positions: 16 Direction of rotation: Standard Connection profile: 16 Contact diameter Power contacts: 1 mm Litz wire cross-section Power contacts min.: 0.08 mm² Litz wire cross-section Power contacts max.: 1 mm² Rated current Power contacts: 8 A Rated voltage: 48 V AC 74 V DC Rated surge voltage: 1.5 kV Overvoltage category: III Degree of pollution: 3 Housing Order information:: Order contact inserts and cable clamping separately Housing material: Metal Type of locking: Screw locking mechanism Pg screw connection: Pg13,5 Degree of protection (plugged in): IP65 IP67 Thread type: M23
Environmental and real-life conditions	Ambient conditions Degree of protection: IP67
