Product properties | Product type: Contact insert Number of positions: 17 Connection profile: 17 Application: Signal Series: NC RC RM TU UC Coding: N Thread type: M23 |
Electrical properties | Contact Contact diameter: 1 mm Min. cross section: 0.22 mm² Max. cross section: 0.56 mm² Max. current: 8 A Nominal voltage UN: 48 VAC 74 VDC Overvoltage category: III Degree of pollution: 3 Rated surge voltage: 1.5 kV |
Material specifications | Insulator material: PA66 Contact material: CuZn Contact surface: Nickel-plated, gold coating |
Connector | Direction of rotation: Standard |
Mechanical properties | Mechanical data Insertion/withdrawal cycles: 50 |
Mounting | Connection method: Crimp connection |
ECLASS | ECLASS-11.0: 27440223 ECLASS-12.0: 27440223 ECLASS-13.0: 27440223 |
ETIM | ETIM 9.0: EC003557 |
UNSPSC | UNSPSC 21.0: 39121400 |
