HC-B 10-TMB-100/O1STM25S-EMV - EMC housing
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Notes | General: For contact inserts HC-B10, BB18, DD42, M, K8/24 |
Product properties | Type: B10 Product type: Housing with bayonet locking Application: EMC No. of cable outlets: 1 Type of the screw connection: 1x M25 Housing type: Sleeve housing Cable outlet: lateral Pg screw connection: none |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/4232a5d417009c45891ae56917a62629/-S204x204-FJPG Width: 57 mm Height: 100 mm Length: 105 mm Installation dimensions Width of the assembly cutout: 35 mm Length of the assembly cutout: 65 mm |
Material specifications | Seal material: NBR, conductive Housing surface material: Powder coating Locking latch material: High-grade steel, handle: PA-GF Housing material: die-cast aluminum |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 Ambient temperature (operation): -40°C ... 125°C |
Mechanical properties | Mechanical data Type of the screw connection: 1x M25 Locking type: Screw |
Mounting | Assembly instructions: In order to guarantee that the protective conductor contact functions even when plugged in at an angle, the two panel-mount flanges must have sufficient electrical contact with the metal mounting panel. If insulating powder coating is present on the control cabinet panel, it should be removed from the profile gasket area in order to ensure optimum shielding. |
ECLASS | ECLASS-11.0: 27440202 ECLASS-12.0: 27440202 ECLASS-13.0: 27440202 |
ETIM | ETIM 9.0: EC000437 |
UNSPSC | UNSPSC 21.0: 31261500 |
