RC-17P1NA2520S - Device connector, rear mounting

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 17, Direction of rotation: Standard, contact connection type: Pin, Solder-in connection, Radial O-ring, 4x ÃË2,7, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242567

Product Code: 1611266 Copia - Copy

Partner cod.: 1611266 Copia - Copy

PHOENIX CONTACT

Tecnichal data

Download

Tecnichal data

Product properties

Product type: Circular connectors (device side)

Connector

Insulating body
Coding: N
Insertion/withdrawal cycles: 50
Connection method: Solder-in connection
Contact switching type: Pin
Application: Signal
Number of positions: 17
Direction of rotation: Standard
Connection profile: 17
Contact diameter Power contacts: 1 mm
Rated current Power contacts: 8 A
Rated surge voltage: 1.5 kV
Overvoltage category: III
Degree of pollution: 3
Housing
Housing material: Metal
Type of locking: Screw locking mechanism
Pg screw connection: none
Degree of protection (plugged in): IP67
Thread type: M23

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Manufacturer_declaration_05486.pdf

Manufacturer_declaration_11087.pdf

Technical_drawing_17025.pdf
