PHOENIX CONTACT 1623277

Not available

HC-26S1N8AQ0DU - Rear panel feed-through

Rear panel feed-through, straight, Screw locking mechanism, M27, number of positions: 26, contact connection type: Socket, Axial O-ring, Central fixing, shielded: yes, degree of protection: IP67, when plugged in, cable diameter range: 2 mm ... 14.5 mm, number of positions: 26, connection method: Crimp connection, series: HC

Product Code: 1623277

Partner cod.: 1623277

PHOENIX CONTACT

Tecnichal data

Technical Specs

Download

Tecnichal data

Notes	General: Order crimp contacts Ã 1 mm separately
Mounting	Mounting: Central fixing Connection method: Crimp connection
Product properties	Product type: Circular connector (cable-side) Number of positions: 26 Connection profile: 26 Application: Signal Series: HC Shielded: yes Coding: N Thread type: M27
Material specifications	Flammability rating according to UL 94: V0 Seal material: NBR Housing material: Metal
Connection data	Conductor connection Connection method: Crimp connection
Electrical properties	Contact Contact diameter: 1 mm Max. current: 8 A Nominal voltage U_N: 48 VAC 74 VDC Overvoltage category: III Degree of pollution: 3 Rated surge voltage: 1.5 kV
Connector	Type: straight Direction of rotation: Standard
Cable/line	External cable diameter: 2 mm ... 14.5 mm
Environmental and real-life conditions	Ambient conditions Degree of protection: IP67, when plugged in Ambient temperature (operation): -20°C ... 125°C Altitude: 2000 m

Technical Specs

ECLASS	ECLASS-11.0: 27440109 ECLASS-12.0: 27440109 ECLASS-13.0: 27440109
ETIM	ETIM 8.0: EC003569
UNSPSC	UNSPSC 21.0: 39121400
