Notes | General: Order crimp contacts 16 x à 1 mm, 2 x à 1.5 mm, 1 x à 1.5 (PE) separately |
Product properties | Product type: Circular connector (cable-side) |
Connector | Insulating body Note: Order information: Order crimp contacts 16x à 1mm, 2x à 1.5mm, 1x à 1.5mm (FE, first) separately for max. connection cross section Coding: N Insulation body material: PA 6.6 Insertion/withdrawal cycles: 100 Connection method: Crimp connection Contact switching type: Pin Application: Signal Number of positions: 19 Direction of rotation: Standard Connection profile: 16+2+FE Contact diameter Power contacts: 1.5 mm Litz wire cross-section Power contacts min.: 0.08 mm² Litz wire cross-section Power contacts max.: 1 mm² Rated current Power contacts: 10 A Rated voltage: 48 VAC 74 VDC Rated surge voltage: 1.5 kV Overvoltage category: II III Degree of pollution: 3 Contact diameter Signal contacts: 1 mm Litz wire cross-section Signal contacts min.: 0.08 mm² Litz wire cross-section Signal contacts max.: 1 mm² Nominal current per signal contact: 8 A Rated voltage Signal contact: 48 VAC Installation height: 2000 m Housing Housing material: Metal Type of locking: SPEEDCON Pg screw connection: none Degree of protection (plugged in): IP67 Thread type: M23 Seal External cable diameter: 3 mm ... 14.5 mm Seal material: NBR |
ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
ETIM | ETIM 9.0: EC002635 |
UNSPSC | UNSPSC 21.0: 39121400 |
