Notes | General: Refer to the data sheet for the range in the download area. |
Product properties | Product type: Cover Product family: ME MAX..DKL Type: Cover Housing type: DIN rail housing Ventilation openings present: no Housing series: ME-MAX |
Dimensions | Width: 22.6 mm Height: 61 mm Depth: 5.5 mm |
Material specifications | Color: transparent Color (Housing): transparent Flammability rating according to UL 94: V2 CTI according to IEC 60112: 250 Insulating material: IIIa Surface characteristics: untreated Housing material: Polycarbonate |
Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 95 % |
PCB data | Type of PCB mount: Latching |
ECLASS | ECLASS-11.0: 27182702 ECLASS-13.0: 27190603 |
ETIM | ETIM 8.0: EC001031 |
UNSPSC | UNSPSC 21.0: 31261500 |
