Notes | General: Refer to the data sheet for the range in the download area. |
Product properties | Product type: Ground contact Product family: UM-PRO Type: bottom PCB level Housing type: Press-drawn section housings Housing series: UM-PRO |
Dimensions | Width: 6 mm Height: 20.8 mm Depth: 25.7 mm PCB design PCB thickness: 1.4 mm ... 1.8 mm |
Material specifications | Color: silver Housing material: Steel |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 105°C Ambient temperature (assembly): -5°C ... 100°C |
PCB data | Thickness of the PCB: 1.4 mm ... 1.8 mm |
Mounting | Mounting type: Screw mounting Tightening torque / speed: Mounting the PCB: 0.5 Nm-0.6 Nm / 500 rpm-1000 rpm |
Packaging specifications | Outer packaging type: Resealable bag |
ECLASS | ECLASS-11.0: 27182701 ECLASS-13.0: 27190605 |
ETIM | ETIM 9.0: EC002779 |
UNSPSC | UNSPSC 21.0: 31261500 |
