AXL F AI8 W 1F - Analog module

AxiolineF, Analog input module, Analog inputs: 8, 0 V ... 5 V, -5 V ... 5 V, 0 V ... 10 V, -10 V ... 10 V, 0 mA ... 20 mA, 4 mA ... 20 mA, -20 mA ... 20 mA, connection technology: 2-conductor, transmission speed in the local bus: 100 Mbps, for SAFEAI applications with service-free continuous operation, degree of protection: IP20, including bus base module and AxiolineF connectors

Product Code: 2702525 Copia - Copy

Partner cod.: 2702525 Copia - Copy

PHOENIX CONTACT

Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/3f783436b27c3846a361ee861b282789/-S204x204-FJPG Width: 53.6 mm Height: 126.1 mm Depth: 54 mm Note on dimensions: The depth applies when a THÃ35-7.5 DIN rail is used (in accordance with ENÃ60715).
Interfaces	AxiolineÃFÃlocal bus Number of interfaces: 2 Connection method: Bus base module Transmission speed: 100 Mbps
System properties	Module Input address area: 16 Byte Output address area: 16 Byte Required parameter data: 27 Byte Required configuration data: 6 Byte
Input data	Analog Input name: Analog inputs Description of the input: Differential inputs, voltage or current can be chosen separately Number of inputs: 8 A/D conversion time: 2 Ãµs A/D converter resolution: 16 bit Connection method: Push-in connection Connection technology: 2-conductor Note regarding the connection technology: shielded, twisted pair Current input signal: 0 mA ... 20 mA 4 mA ... 20 mA -20 mA ... 20 mA Input resistance current input: 104 Ã© (typical) Voltage input signal: 0 V ... 5 V -5 V ... 5 V 0 V ... 10 V -10 V ... 10 V Input resistance of voltage input: 268 kÃ© (typical) Data formats: IB IL, S7-compatible Input filter: 30 Hz, 12 kHz and mean-value generation (can be parameterized) Filtering: RFI filtering / passive TP 1st order Limit frequency (3 dB): 30 Hz 12 kHz (in fast mode) Common mode voltage range signal - ground: -50 VÃDC ... 50 VÃDC Measured value representation: 16 bits (15 bits + sign bit) Protective circuit: Transient protection of inputs; Suppressor diode Overload protection of the current inputs; No; Ã±5.2ÃVÃDC, maximum, I_max = 50ÃmA Overload protection of the voltage inputs; Ã±30 V DC, maximum
Product properties	Type: block modular Product type: I/O component Product family: AxiolineÃF Mounting position: any (no temperature derating) Scope of delivery: including bus base module and AxiolineÃF connectors Insulation characteristics Overvoltage category: II (IEC 60664-1, ENÃ60664-1) Pollution degree: 2 (IEC 60664-1, ENÃ60664-1)
Electrical properties	Maximum power dissipation for nominal condition: 4.2 W Potentials Power consumption: typ. 1.255 W (at U_Bus and U_A (from HWÃ05)) typ. 1.365 W (at U_Bus and U_A (up to HWÃ04)) max. 1.62 W (at U_Bus and U_A (from HWÃ05)) max. 1.605 W (at U_Bus and U_A (up to HWÃ04)) Potentials: AxiolineÃF local bus supply (U Supply voltage: 5 VÃDC (via bus base module) Current draw: max. 130 mA (up to HW 04) max. 60 mA (from HW 05) typ. 105 mA (up to HW 04) typ. 45 mA (from HW 05) Power consumption: max. 650 mW (up to HW 04) max. 300 mW (from HW 05) typ. 525 mW (up to HW 04) typ. 225 mW (from HW 05) Potentials: Supply for analog modules (U Supply voltage: 24 VÃDC Supply voltage range: 19.2 VÃDC ... 30 VÃDC (including all tolerances, including ripple) Current draw: max. 55 mA (from HW 05) max. 45 mA (up to HW 04) typ. 43 mA (from HW 05) typ. 35 mA (up to HW 04) Power consumption: max. 1.32 W (from HW 05) max. 1.08 W (up to HW 04) Protective circuit: Surge protection; electronic (35 V, 0.5 s) Reverse polarity protection; Polarity protection diode Transient protection; Suppressor diode Electrical isolation/isolation of the voltage ranges Test voltage: 5ÃV supply of the local bus (U_Bus) / 24ÃV supply (I/Os): 500 VÃAC, 50 Hz, 1 min. Test voltage: 5ÃV supply of the local bus (U_Bus) / functional ground: 500 VÃAC, 50 Hz, 1 min. Test voltage: 24ÃV supply (I/O) / functional ground: 500 VÃAC, 50 Hz, 1 min.
Connection data	Connection technology Connection name: AxiolineÃF connector Note on the connection method: Please observe the information provided on conductor cross sections in the Ã¢Ã¢¬ÃAxiolineÃF: system and installationÃ¢Ã¢¬ user manual. Conductor connection Connection method: Push-in connection Conductor cross section rigid: 0.2 mm² ... 1.5 mm² Conductor cross section flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 8 mm AxiolineÃF connector Connection method: Push-in connection Note on the connection method: Please observe the information provided on conductor cross sections in the Ã¢Ã¢¬ÃAxiolineÃF: system and installationÃ¢Ã¢¬ user manual. Conductor cross section, rigid: 0.2 mm² ... 1.5 mm² Conductor cross section, flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 8 mm
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -25°C ... 60°C -10°C ... 35°C (annual average) Degree of protection: IP20 Air pressure (operation): 70 kPa ... 106 kPa (up to 3000Ãm above sea level) Air pressure (storage/transport): 70 kPa ... 106 kPa (up to 3000Ãm above sea level) Ambient temperature (storage/transport): -40°C ... 85°C Permissible humidity (operation): 5 % ... 95 % (Non-condensing, annual average < 75%) Permissible humidity (storage/transport): 5 % ... 95 % (Non-condensing, annual average < 75%)
Standards and regulations	Protection class: III (IEC 61140, ENÃ61140, VDEÃ0140-1)
Mounting	Mounting type: DIN rail mounting Mounting position: any (no temperature derating)
