UEGH 25 - Electronic housing
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Type: Connection system integrated, housing closed Complete housing equipped with 6 screw connections per side, for two printed-circuit boards each Product type: Complete housing Product family: UEGH Number of positions: 12 Pitch: 5 mm Number of rows: 2 Housing type: Complete housing Housing series: UEGH Pin layout: Linear pinning |
Electrical properties | Nominal voltage UN: 500 V Nominal current IN: 10 A |
Dimensions | Width: 25 mm Installed height: 106.7 mm Height NS 35/7,5: 106.7 mm Depth: 79 mm Length: 79 mm Pitch: 5 mm |
Material specifications | Color: green Flammability rating according to UL 94: V0 Surface characteristics: untreated Housing material: Polyamide |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 105°C |
Mounting | Mounting type: Soldering Pin layout: Linear pinning Connection method: Screw connection |
ECLASS | ECLASS-11.0: 27182702 ECLASS-13.0: 27190501 |
ETIM | ETIM 8.0: EC001031 |
UNSPSC | UNSPSC 21.0: 31261500 |
