| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/4466fa705ece7847b56185793696fa26/-S204x204-FJPG
Width: 80 mm
Height: 119.8 mm
Depth: 71.5 mm
Note on dimensions: Specfications with connectors
|
| Notes | Utilization restriction
CCCex note: Use in potentially explosive areas is not permitted in China.
|
| Interfaces | Modbus/RTU
Number of interfaces: 1
Connection method: D-SUB-9 female connector
Note on the connection method: Electrically isolated supply, shielding directly connected to functional ground
Transmission speed: 1.2 kBit/s ... 115.2 kBit/s (can be parameterized)
Inline local bus
Number of interfaces: 1
Connection method: Inline data jumper
Transmission speed: 500 kbps / 2 Mbps (automatic detection, no combined system)
|
| System properties | System limits
Number of supported devices: max. 63 (per station)
Number of local bus devices that can be connected: max. 61 (The on-board I/Os are two devices)
Number of devices with parameter channel: max. 8
Number of supported branch terminals with remote bus branch: 0
Module
ID code (hex): none
Input address area: 8 bit
Output address area: 4 bit
Register length: 16 bit
|
| Input data | Digital
Input name: Digital inputs
Description of the input: EN 61131-2 type 1
Number of inputs: 8
Connection method: Inline connector
Connection technology: 3-conductor
Input voltage: 24 VDC
Input voltage range "0" signal: -30 VDC ... 5 VDC
Input voltage range "1" signal: 15 VDC ... 30 VDC
Nominal input voltage UIN: 24 VDC
Nominal input current at UIN: typ. 3 mA
Typical input current per channel: typ. 3 mA
Typical response time: approx. 500 µs
Delay at signal change from 0 to 1: 1.2 ms
Delay at signal change from 1 to 0: 1.2 ms
|
| Output data | Digital
Output name: Digital outputs
Connection method: Inline connector
Connection technology: 3-conductor
Number of outputs: 4
Protective circuit: Short-circuit and overload protection; Freewheeling circuit in the output driver
Output voltage: 24 VDC -1V (At nominal current)
Maximum output current per module: max. 2 A
Nominal output voltage: 24 VDC
Output current when switched off: max. 10 µA (When not loaded, a voltage can be measured even at an output that is not set.)
Nominal load, inductive: 12 VA (1.2 H, 48 é)
Nominal load, lamp: 12 W
Nominal load, ohmic: 12 W
Reverse voltage resistance to short pulses: Reverse voltage proof
Behavior with overload: Auto restart
Behavior with inductive overload: Output can be destroyed
Behavior at voltage switch-off: The output follows the power supply without delay
Signal delay: typ. 1.2 ms
Overcurrent shut-down: min. 0.7 A
|
| Product properties | Type: modular
Product type: I/O component
Product family: Inline
Scope of delivery: including inline connectors, marking fields, and end plate
No. of channels: 12
Diagnostics messages: Short-circuit or overload of the digital outputs yes
Sensor supply failure yes
Failure of the actuator supply yes
Insulation characteristics
Overvoltage category: II (IEC 60664-1, EN60664-1)
Pollution degree: 2 (IEC 60664-1, EN60664-1)
|
| Electrical properties | No. of channels: 12
Maximum power dissipation for nominal condition: 23.5 W
Potentials
Power consumption: typ. 3 W (entire device)
Potentials: Bus coupler supply U
Supply voltage: 24 VDC (via Inline connector)
Supply voltage range: 19.2 VDC ... 30 VDC (including all tolerances, including ripple)
Current draw: max. 0.94 A (with max. number of connected I/O terminal blocks)
typ. 40 mA (without connected I/O terminal blocks)
Potentials: Communications power (U
Supply voltage: 7.5 VDC
Potentials: Supply of analog modules (U
Supply voltage: 24 VDC
Supply voltage range: 19.2 VDC ... 30 VDC (including all tolerances, including ripple)
Potentials: Main circuit supply (U
Supply voltage: 24 VDC (via Inline connector)
Supply voltage range: 19.2 VDC ... 30 VDC (including all tolerances, including ripple)
Current draw: max. 8 ADC
min. 3 mA (without connected peripherals)
Potentials: Segment circuit supply (U
Supply voltage: 24 VDC (via Inline connector)
Supply voltage range: 19.2 VDC ... 30 VDC (including all tolerances, including ripple)
Current draw: max. 8 ADC
min. 3 mA (without connected peripherals)
Electrical isolation/isolation of the voltage ranges
Test voltage: Modbus interface 1 / Modbus interface 2: 500 VAC, 50 Hz, 1 min.
Test voltage: Modbus interface 1 / communications power (UBK, UL, UANA): 500 VAC, 50 Hz, 1 min.
Test voltage: Modbus interface 1 / I/O (UM, US): 500 VAC, 50 Hz, 1 min.
Test voltage: Modbus interface 1 / functional ground: 500 VAC, 50 Hz, 1 min.
Test voltage: Modbus interface 2 / communications power (UBK, UL, UANA): 500 VAC, 50 Hz, 1 min.
Test voltage: Modbus interface 2 / I/O (UM, US): 500 VAC, 50 Hz, 1 min.
Test voltage: Modbus interface 2 / functional ground: 500 VAC, 50 Hz, 1 min.
Test voltage: Communications power (UBK, UL, UANA) / I/O (UM, US): 500 VAC, 50 Hz, 1 min.
Test voltage: Communications power (UBK, UL, UANA) / functional ground: 500 VAC, 50 Hz, 1 min.
Test voltage: I/O (UM, US) / functional ground: 500 VAC, 50 Hz, 1 min.
|
| Connection data | Connection technology
Connection name: Inline connector
Conductor connection
Connection method: Spring-cage connection
Conductor cross section rigid: 0.08 mm² ... 1.5 mm²
Conductor cross section flexible: 0.08 mm² ... 1.5 mm²
Conductor cross section AWG: 28 ... 16
Stripping length: 8 mm
Inline connector
Connection method: Spring-cage connection
Conductor cross section, rigid: 0.08 mm² ... 1.5 mm²
Conductor cross section, flexible: 0.08 mm² ... 1.5 mm²
Conductor cross section AWG: 28 ... 16
Stripping length: 8 mm
|
| Environmental and real-life conditions | Ambient conditions
Ambient temperature (operation): -25°C ... 60°C
Degree of protection: IP20
Air pressure (operation): 70 kPa ... 106 kPa (up to 3000m above sea level)
Air pressure (storage/transport): 70 kPa ... 106 kPa (up to 3000m above sea level)
Ambient temperature (storage/transport): -40°C ... 85°C
Permissible humidity (operation): 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport): 10 % ... 95 % (non-condensing)
|
| Standards and regulations | Protection class: III (IEC 61140, EN61140, VDE0140-1)
|
| Mounting | Mounting type: DIN rail mounting
|
Not available
