Notes | General: Refer to the data sheet for the range in the download area. |
Product properties | Product type: Cover Type: Insertion plate Housing type: DIN rail housing Ventilation openings present: no Housing series: ME-MAX |
Dimensions | Width: 19.2 mm Height: 73.6 mm Depth: 1 mm |
Material specifications | Color: light grey (7035) Flammability rating according to UL 94: V0 CTI according to IEC 60112: 600 Surface characteristics: untreated Housing material: Polyamide |
Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 55°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 80 % |
Mounting | Mounting type: Slot |
ECLASS | ECLASS-11.0: 27182702 ECLASS-13.0: 27190605 |
ETIM | ETIM 8.0: EC001031 |
UNSPSC | UNSPSC 21.0: 31261500 |
