CB S-BE - Base element

Solder base element for PCB mounting for accommodating CB TM... or CB E... device circuit breakers
Product Code: 2905067
Partner cod.: 2905067
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Download
Tecnichal data
Product propertiesType: Base element, PCB mounting
Product type: Base element
Product family: CB BE
Electrical propertiesGeneral
Rated insulation voltage Ui: 80 VÂDC
277 VÂAC
Rated surge voltage: 2.5 kV
Insertion/withdrawal cycles: 50
Main circuit
Rated voltage: 80 VÂDC
277 VÂAC
Rated current IN: 16 A
Remote indication circuit
Rated voltage: 80 VÂDC
277 VÂAC
Rated current IN: 1 A
DimensionsDimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/7cd165a0ac04734c9d5d8cd41b592e54/-S204x204-FJPG
Width: 12.3 mm
Height: 34.8 mm
Depth: 36.4 mm
Material specificationsFlammability rating according to UL 94: V-0
Housing material: PA 6.6
Environmental and real-life conditionsAmbient conditions
Degree of protection: IP30 (Plug-in area with plugged-in device)
IP00 (Connection area)
Ambient temperature (operation): -30°C ... 60°C
Ambient temperature (storage/transport): -40°C ... 80°C
Humidity test: 240 h, 95 % RH, 40°C
Standards and regulationsStandards/specifications: DINÂENÂ50155
IEC 60068-2
MountingMounting type: On PCB
Connection method: Solder connection
