PHOENIX CONTACT 2909895

Not available

ME DH36 NS 35 - Spacer

Spacers, for protection of the input or output contacts for DIN rail NS 35, width [B] 36 mm

Product Code: 2909895

Partner cod.: 2909895

PHOENIX CONTACT

Tecnichal data

Technical Specs

Download

Tecnichal data

Notes	General: Refer to the data sheet for the range in the download area.
Product properties	Product type: Mounting material Housing type: DIN rail housing Ventilation openings present: no Housing series: ME
Material specifications	Color: green (6021) Flammability rating according to UL 94: V0 Surface characteristics: untreated Housing material: Polyamide
Environmental and real-life conditions	Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 55°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 80 %

Technical Specs

ECLASS	ECLASS-11.0: 27182702 ECLASS-13.0: 27190605
ETIM	ETIM 9.0: EC001031
UNSPSC	UNSPSC 21.0: 31261500

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Material_description_00001.pdf
