| Product properties | Product type: Corrugated pipe screw connection Application: Cable gland Type: Outer thread Cable outlet: angled Thread type: Pg |
| Dimensions | Width: 17 mm Height: 34 mm Length: 33 mm Diameter: 16 mm |
| Material specifications | Material: PA 6 Flammability rating according to UL 94: V2 Material for screw connection: PA Components: free from silicone, halogen, and cadmium |
| Cable/line | Halogen-free: yes |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 Ambient temperature (operation): -40°C ... 120°C |
| ECLASS | ECLASS-11.0: 27430311 ECLASS-13.0: 27430311 ECLASS-12.0: 27430311 |
| ETIM | ETIM 9.0: EC001178 |
| UNSPSC | UNSPSC 21.0: 39121300 |
