| Product properties | Type: USB-A Socket Product type: Female insert Number of positions: 4 Connection profile: USB Number of slots: 1 Shielded: no |
| Electrical properties | Rated voltage (III/3): 30 V Rated current: 1 A Insulation resistance: ⥠1 Gé Transmission medium: Copper Transmission characteristics (category): USB 2.0 |
| Connection data | Connection technology Connection method: Flat-ribbon cable connection |
| Dimensions | Width: 22.8 mm Height: 17.7 mm Length: 36.1 mm |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Gold Contact carrier material: Thermoplastic Housing material: Plastic |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠1000 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -15°C ... 65°C |
| Mounting | Connection method: Flat-ribbon cable connection |
| ECLASS | ECLASS-11.0: 27440223 ECLASS-12.0: 27440223 ECLASS-13.0: 27440223 |
| ETIM | ETIM 9.0: EC003557 |
| UNSPSC | UNSPSC 21.0: 39121400 |
