| Product properties | Type: FSMA Product type: Data connector (cable side) Number of positions: 2 Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Attenuation: ⥠2 dB (Insertion attenuation) Transmission medium: FO Transmission characteristics (category): MM |
| Connection data | Connection technology Connection method: Cable connection |
| Dimensions | Width: 8.1 mm Length: 83 mm |
| Material specifications | Material: Metal Housing material: Metal |
| Cable/line | Cable type: PCF 200/230 Single wires External cable diameter (): 2.9 mm ... 2.9 mm Individual wire diameter: 2.9 mm FO cable Fiber: 200/230µm Fiber type: PCF Transmission medium: FO |
| Characteristics | Attenuation: ⥠2 dB (Insertion attenuation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -25°C ... 70°C Ambient temperature (storage/transport): -40°C ... 80°C Ambient temperature (assembly): 0°C ... 50°C |
| Mounting | Mounting type: For field assembly cable layer type: Indoors Connection method: Cable connection |
| ECLASS | ECLASS-11.0: 19170122 ECLASS-12.0: 19170122 ECLASS-13.0: 19170122 |
| ETIM | ETIM 9.0: EC001122 |
| UNSPSC | UNSPSC 21.0: 43223300 |
