| Product properties | Type: B24 Product type: Connector set Number of positions: 24 Connection profile: 24+PE Application: Standard No. of cable outlets: 1 Housing type: Complete housing Seal present: yes Protective cover: yes Series: HC-B Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Electrical properties | Rated voltage (III/3): 500 V Rated surge voltage: 6 kV Rated current: 16 A |
| Connection data | Connection method: Push-in connection Connection technology: Push-in connection Conductor cross section: 0.14 mm² ... 2.5 mm² (with ferrule) Connection cross section AWG: 26 ... 14 Stripping length: 8 mm ... 10 mm |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/3fed82a08fb72440817e8f854f474f40/-S204x204-FJPG Width: 53 mm Height: 90.5 mm Length: 140.5 mm Drill hole distance, horizontal: 130 mm Drill hole distance, vertical: 32 mm Hole diameter: 4.5 mm Installation dimensions Width of the assembly cutout: 35 mm Length of the assembly cutout: 113 mm |
| Material specifications | Material: Die-cast aluminum, saltwater-resistant PA Flammability rating according to UL 94: V0 Seal material Profile gasket: NBR Seal material Flat gasket: NBR Contact material: Copper alloy Contact surface material: Ag Contact carrier material: PC Locking latch material: PA Impact strength: IK08 |
| Cable/line | External cable diameter (): 15 mm ... 21 mm 17 mm ... 21 mm (for UL 514 B) |
| Mechanical properties | Mechanical data Locking type: Latch Insertion/withdrawal cycles: ⥠500 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 IP67 Impact strength: IK08 Ambient temperature (operation): -40°C ... 100°C |
| Mounting | Mounting type: Screw mounting Assembly instructions: Coding also using the CP-HC (1686478) coding profiles. HC-B6../ HC-B10..for two coding profiles. HC-B16../ HC-B24..for four coding profiles. Connectors may only be operated when there is no load/the power is switched off. Can be used for solid wires and stranded wires with ferrule. Connection method: Push-in connection |
| ECLASS | ECLASS-11.0: 27440101 ECLASS-12.0: 27440113 ECLASS-13.0: 27440113 |
| ETIM | ETIM 9.0: EC002636 |
| UNSPSC | UNSPSC 21.0: 39121400 |
