Notes | General: for contact inserts HC-A03, A04, D07, D08, Q02, Q03, Q04, Q05, Q07, Q12 |
Product properties | Type: D7 Product type: Housing with locking latch Application: Standard No. of cable outlets: 1 Type of the screw connection: M25 Housing type: Coupling housings Protective cover: yes Shielded: no Cable outlet: straight Pg screw connection: with |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/066834078eeedb4e8b8b179e719337e2/-S204x204-FJPG Width: 26.5 mm Height: 60.5 mm Length: 26.5 mm |
Material specifications | Flammability rating according to UL 94: V0 (Housing) V0 (Interlock) V0 (Protective cover) Material, protective cover: PA Locking latch material: PA Impact strength: IK06 Housing material: PA |
Mechanical properties | Mechanical data Type of the screw connection: M25 Locking type: Latch |
Cable/line | External cable diameter (): 10 mm ... 16 mm Tightening torque, union nut: 5.00 Nm |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 (when plugged in or with locked protective cover) Impact strength: IK06 Ambient temperature (operation): -40°C ... 125°C |
ECLASS | ECLASS-11.0: 27440202 ECLASS-12.0: 27440202 ECLASS-13.0: 27440202 |
ETIM | ETIM 9.0: EC000437 |
UNSPSC | UNSPSC 21.0: 31261500 |
